LTPS

Apple was the first company to develop LTPO backplanes and it adopted this innovative and energy-efficient backplane technology back in 2018 in the Watch Series 4. LTPO combines Oxide-TFT and LTPS, by using the IGZO in some of the switching TFTs and LTPS in the remaining switching TFTs and all the driving TFTs. LTPO can reduce the power consumption by 5-15%, and enables variable refresh rate.

According to reports from Korea, Apple developed its 2nd-Gen LTPO backplane technology, that uses the IGZO in all the driving TFTs, and uses LTPS only in the remaining switching TFTs. This leads to higher efficiency compared to the first-generation LTPO backplane.

In 2021, we reported that two researchers working at Samsung Display were convicted of handing over OLED technology to other companies, and are being sent to prison for two years. Representative and directors of the company that bought the technology was also sent to prison and the company was fined. The technology in question relates to Optical Adhesive Materials used in OLED production processes. The arrest of these employees was reported earlier in 2020.

It is now reported that another employee of Samsung Display, also involved in that case (seems to be he was the main organizer of the outfit) fled Korea following his indictment, but has now returned voluntarily to Korea and has been arrested and is now bring charged with violating unfair competition laws in Korea.

China-based Visionox demonstrated many OLED displays and new technologies at Display Week 2023.

So first up, we have some rollable and foldable OLEDs. You can see some impressive looking such flexible OLEDs in the video above, and Visionox featured many such displays at their booth.

This is a sponsored post by Amorphyx, where display industry consultant Ian Hendy has interviewed Amorphyx's CEO John Brewer

Q: Can you start by telling us a little about what Amorphyx does, John?

Amorphyx has several fundamentally new technology platforms that provide for TFT performance improvements in three areas: (1) Switching speeds, with options to move to the Tera-Hz range ultimately, (2) Power, where the IGZO AMeTFT can achieve even lower power performance than today’s LTPO OLED Pro Motion displays and better refresh range, and (3) Small transistor size.

Our technology platforms are lower cost than the alternatives, and move from amorphous and crystalline semiconductor approaches, to devices based on different effects that do not have a semiconductor at all, yet can still drive a display, drive current, deliver grey scale and switch very fast. Or they can operate a flex IC at higher clock speeds than known today.

For now, our main commercial focus is on IGZO AMeTFT which is fundamentally a potential replacement transistor for LTPS or LTPO used in modern OLED phones and has the capability to replace more highly compensated LTPO circuits in modern Smartphone displays due to enhanced stability.

This is a sponsored post by Coherent

Lasers are utilized for numerous processes in flexible OLED production, just as they are in the manufacture of other display technologies. In fact, it can be reasonably claimed that lasers are a key enabling technology in the fabrication of modern, flat panel displays. And it’s likely that they will continue to perform essential fabrication steps as flexible and foldable displays become more commonplace.

There is a variety of processes within the flexible display production line where lasers have an essential contribution to enable high throughput, high yield mass production. Nowadays, the complexity of the displays is getting larger and the number and tasks of lasers within flexible OLED production is increasing.

For this reason, choosing the right laser really means choosing the right laser supplier. Manufacturers need a partner who has the specific technical and applications development resources to identify the best and most cost-effective solution. Coherent is that partner

TCL (CSoT) announced that the company has finalized the development of several new OLED technologies, which has been deployed at the company's production lines.

The first technology is LTPO, or Low-Temperature Polycrystalline Oxide, an OLED backplane technology developed originally by Apple. LTPO enables variable refresh rates, and TCL's technology can support a wide range of frequencies, from 1Hz to 144Hz.

BOE has been aiming to supply OLED displays for Apple for a long time. In 2020 BOE did not pass Apple's OLED quality test for the iPhone 12 , but later it it did manage to enter Apple's supply chain, only for aftermarket (refurbished models) 6.06" LTPS AMOLED displays.

According to CINNO Research, BOE recently signed a contract with Apple to supply OLED panels for the iPhone 14, which will be launch in October 2022. This will be the first time BOE is supplying OLEDs to a new Apple device. CINNO says that the contact amounts to 50 million panels, about 25% of Apple's total OLED supply. These will be 6.1" LTPS AMOLED displays.

BOE has been aiming to supply OLED displays for Apple for a long time. In 2020 BOE did not pass Apple's OLED quality test for the iPhone 12 , but later it it did manage to enter Apple's supply chain, only for aftermarket (refurbished models) 6.06" LTPS AMOLED displays.

According to reports in Korea, for Apple's 2014 models, which will be introduced in 2022, BOE aims to supply similar panels (to standard models). BOE is also aiming to be the producer of Apple's iPhone 15 Pro series in 2023. The company is looking to introduce LTPO technology at its B12 AMOLED line at Chongqing, the line which has only recently started production.

DSCC posted an interesting article, comparing the production costs of OLED vs mini-LED panels for IT. DSCC estimates that for tablets and notebooks, a tandem structure will be used, and the panels will be based on rigid substrates.

In the chart above you see a production cost comparison, between 2021 and 2025, for 12.9" panels. DSCC looks at two OLED production options: a tandem OLED panel with an LTPO backplane produced in a 6-Gen fab, and a similar panel that uses an Oxide-TFT backplane and produced in a larger 8.5-Gen fab. As you can see, OLED panels are more cost effective, and will remain so throughout the forecast period.
